Corner connector 100 mm – robust connection for large-format textile tension frame constructions

The 100 mm corner connector was specifically developed for the secure and stable connection of textile tension frames. Its robust construction makes it particularly suitable for large-format frame solutions and ensures a permanently durable and precise corner joint.

The combination of steel and aluminum unites high stability with precise workmanship and supports exact alignment of the profiles. This results in a high-quality frame construction with high dimensional stability – ideal for demanding indoor applications.

Due to the profile size, a total of two sets of corner connectors are required to manufacture a square textile tension frame.

Product advantages at a glance

• Suitable for 100 mm textile tension frames

• Robust and durable corner joint

• High-quality construction in steel and aluminum

• Secure fastening with screws and T-nuts

• Simple and precise assembly

• Ideal for large-format textile tension frames

• High dimensional stability in large frame formats


General technical data of the corner connector

• Design: Corner connectors made of steel / aluminum

• Suitable for: 100 mm textile tension frames

• Connection: Cylinder head bolts M6 × 12 mm

• Fastening: T-nuts M6
• Contents per set:
  -2 screws
  -2 T-nuts
• Packaging unit: 4 pieces
• Weight per set: 0.28 kg
• Required: 2 sets for a square textile tension frame (8 corner connectors)


Construction of the corner connector

The corner connector is inserted into the designated areas of the textile tension frame and securely connects the individual profiles. The combination of screw connections and T-nuts ensures a stable corner construction and supports the high load-bearing capacity of the finished frame.

Thanks to its simple assembly, the system is ideal for individual textile tension frames as well as large-format applications.

areas of application

Large-format textile tension frames
Ideal for large frame formats with high demands on stability and dimensional accuracy.

Wall frame with fabric banner
Suitable for high-quality fabric banner presentations with secure corner connections.

Freestanding textile tension frames
Ideal for stable frame systems with high load-bearing capacity.

Shopfitting & Retail
Perfect for large-scale brand and product presentations.

Exhibition stand construction & brand presentations
Suitable for professional presentation systems and large-format textile applications.

Conclusion

The 100 mm corner connector is the ideal accessory for stable and robust textile tension frame constructions, especially for large frame sizes. The combination of steel and aluminum, the secure fastening, and the high stability create the perfect foundation for durable and professional tension frame systems.
